BDS Suspension BDS1801H - 2019-2023 Chevy-GMC 1500 6in System
BDS Suspension BDS1801H - 2019-2023 Chevy-GMC 1500 6in System

BDS Suspension BDS1801H - 2019-2023 Chevy-GMC 1500 6in System

Vendor: BDS Suspension
SKU: BLDV_BDS1801H
Availability: 10 In Stock
Product Type: Suspension Lift Kit
$2,200.00 USD
$2,252.00
$2,200.00 USD
Found Better Price? Get Price Match!
Take 10% off select products at checkout.
Savings auto-applies on selected products at checkout. Exclusions apply.
  • TruckPoint: Truck Accessories - Car Parts - Canadian Auto Parts
Description
Description
x

BDS corrects steering geometry at the new taller ride height using a pair of high-strength CNC machined ductile cast iron steering knuckle design to work with replacement tie rod ends to maintain steering angles for proper function and ESC compatibility.

Unlock serious off-road performance with the BDS 6" Suspension Lift System, engineered for maximum clearance, durability, and comfort. Designed to maintain ESC system compatibility and factory ride quality, this lift kit is packed with premium components for serious enthusiasts and weekend warriors alike.

🔧 Key Features & Benefits

  • Maximum Ground Clearance:
    Heavy-duty, precision laser-cut 1/4" steel high-clearance crossmembers are paired with a rigid bolt-on HD front skid plate, offering unbeatable underbody protection.

  • ESC-Compatible Steering Knuckles:
    CNC-machined ductile cast iron knuckles retain factory steering geometry and electronic stability control (ESC) performance, ensuring safe and predictable handling at lifted ride heights.

  • Durable Upper Control Arms:
    High-strength replacement upper control arms offer long-lasting serviceability and improved suspension articulation.

  • Differential Drop Brackets:
    Multipoint relocation brackets reposition the front differential to correct CV angles, reducing stress on components and improving driveline longevity.

  • Factory Protection Plus Warranty:
    Get peace of mind with BDS’s drivetrain warranty, protecting factory components from potential damage due to the lift kit.

🚙 Recommended Tire & Wheel Fitment

(Some trimming may be required for optimal clearance)

  • 35x12.5 on 17x9 wheels with 4.5” backspacing

  • 35x12.5 on 20x9 wheels with 6.25” backspacing

  • 37x12.5 on 20x9 wheels with 6.25” backspacing

🛠 Front Shock Options

Strut Spacer Kit (Base Option)

  • Heavy-duty steel spacers preserve factory ride quality

  • Fast and straightforward installation

FOX 2.0 Performance Series

  • CNC-machined 6061-T6 aluminum body, rust-resistant

  • 5/8” heat-treated chrome-plated shaft

  • IFP monotube with race-developed high-flow pistons

  • Application-specific valving for superior on/off-road control

🛠 Rear Shock Options

NX2 Nitro Series

  • Twin-tube nitrogen-charged shocks with 10-stage valving

  • Dual-welded ends for extreme durability

  • High-flow 1-3/8” piston and self-lubricating seals

  • Powder-coated silver finish

FOX 2.0 Performance Series

  • IFP monotube with precision-machined aluminum ends

  • Same race-proven performance and durability as front shocks

⚠️ Important Fitment Notes

  • Frame bracket modification required

  • Factory 17–18” wheels not compatible due to tie rod interference

  • Stock 20” wheels may be reused

  • All wheels should be test-fit before tire mounting to ensure caliper and steering clearance

  • Coilover kits yield approximately 6.5” lift height

  • 2.7L Turbo models require the Diesel-specific kit for proper skid plate alignment

  • Will not fit models equipped with ARC suspension

  • Vehicles with mono-leaf rear springs require Part #UBT4064 (Qty 4)

🧰 Installation Info

  • Estimated Install Time: ~8 Hours

  • Difficulty Level: Advanced

  • Specialty Tools Required:
    36mm socket, cutoff wheel, ball joint separator, reciprocating saw, welding equipment

📐 Kit Specifications

Component Detail
Front Lift Method Crossmember
Rear Lift Method Block
Front Lift Height 6"
Rear Lift Height 4"
Shocks Included Yes (NX2 or FOX options)

🛡️ Dominate Trails. Ride with Confidence.

Whether you're upgrading for looks, off-road adventure, or clearance for bigger tires, the BDS 6" Lift Kit delivers a no-compromise suspension upgrade with premium components and a reliable factory drivetrain warranty. Level up your truck’s capabilities today.


Specifications:

Description_ASC Requires frame bracket modification.
Description_ASC Factory 17-18" wheels cannot be reinstalled due to tie rod end interference stock 20" wheels can be reinstalled
Description_ASC 17" wheels with 4.5" backspacing should be test fit prior to mounting the tire to ensure proper clearance to the steering knuckle / tie rod
Description_ASC All aftermarket wheels should be test fit prior to mounting the tire to ensure proper clearance to the brake caliper. Some wheel profiles will not clear the brake caliper. These can be test fitted before the vehicle is lifted in a stock condition
Description_ASC Actual ride height on coilover kits is closer to 6.5'' of lift
Description_ASC 2.7L models use diesel kit for proper skid plate fitment
Description_ASC Will NOT fit models with a single leaf spring (monoleaf) rear suspension.
Description_DES 2019-2023 GM 1500 6in Suspension System
Description_EXT 2019-2023 Chevy-GMC 1500 6in Suspension System
Description_FAB High clearance crossmember design maximizes ground clearance
Description_FAB Robust steering knuckles maintain ESC system compliance
Description_FAB High-strength replacement upper control arms provide durability and serviceability
Description_FAB HD skid plate system improved offroad protection
Description_FAB Multipoint differential relocation brackets to secure the front axle and improve CV angles
Description_FAB Factory Protection Plus drivetrain warranty included
Description_MKT BDS steps up the performance and capability of the Chevy Silverado and GMC Sierra 1500 trucks with 6-inch suspension lift kit. Designed to improve stance performance and capability this kit includes everything necessary to set your truck up right with clearance for up to 35" tires
Description_MKT This kit takes advantage of BDS's tried and true high-clearance design for improved ground clearance strength and offroad protection while correcting suspension and steering geometry for great on-road handling characteristics. Up front the kit utilizes top mounted strut spacers high-arched 1/4-inch thick steel crossmembers along with a multipiece differential relocation brackets and heavy duty skid plates built for offroad protection. Steering geometry is corrected at the new taller ride height with CNC-machined ductile iron steering knuckles and replacement tie rod ends allowing for ESC system compatibility. These combined with the provided sway bar drops bump stop extensions brake line brackets CV spacers supplied hardware and more provide a comprehensive front suspension lift ready for whatever you throw at it.
Description_MKT In the rear BDS offers a heavy duty lift block to lift and level that stance. The lift block installs in place of the stock block and retains ride quality and load capacity. Also for the rear are new u-bolts brake line brackets and precision tuned NX2 Nitro or premium FOX 2.0 Performance Series shocks.
Description_MKT High Clearance Crossmembers
Description_MKT BDS maximizes ground clearance with their heavy duty 1/4-inch thick laser cut perfect fit crossmembers. Paired with a front skid plate system that bolts together to create a rigid subframe while adding extra protection.
Description_MKT Heavy Duty Steering Knuckles
Description_MKT BDS corrects steering geometry at the new taller ride height using a pair of high-strength CNC machined ductile cast iron steering knuckle design to work with replacement tie rod ends to maintain steering angles for proper function and ESC compatibility.
Description_SHO Suspension lift kit
Description_DEF Suspension Lift Kit
