Bilstein 24-337052 B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber
- Regular price
- $166.00 USD
- Regular price
-
$205.00 - Sale price
- $166.00 USD
- Unit price
- per
Take 10% off select products at checkout.
Savings auto-applies on selected products at checkout. Exclusions apply.
Couldn't load pickup availability
Description
xProduct Description
Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coil over style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0 to 3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46 millimeter digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.
Shock Absorber; B8 5100 (Ride Height Adjustable); Nitrogen Gas Charged; Without Reservoir; Limited Lifetime Warranty; Non Adjustable; 21.65 Inch Extended Height/ 16.28 Inch Compressed Height; Stem Upper Mount/ Bar Pin Lower Mount; Without Shock Boots; Zinc Plated; Single
Features & Benefits
- Higher Power Reserves And A Longer Service Life Even When Pulling Trailers Or Driving Offroad
- Optimum Grip And Enhanced Lane Stability In Day To Day And Extreme Situations
- Perceivably Enhanced Safety
- Perfect In Combination With Lifting Kits
- BILSTEIN Gas-Pressure Technology
- BILSTEIN Mono-Tube Upside-Down Technology Possible
- Individually Fine-Tuned In The BILSTEIN Road Test
- Limited Lifetime Warranty
Attributes
- Type: Nitrogen Gas Charged
- With Coil Spring: No
- Extended Length (IN): 21.65 Inch
- Compressed Length (IN): 16.28 Inch
- Upper Mounting Style: Stud
- Lower Mounting Style: Cross Pin
- Adjustable Valving: No
- Quantity: Single
- Universality: Vehicle Specific
- Internal Design: Monotube
- Body Color: Silver
- Ride Height Adjustable: Yes
- With Reservoir: No
- Includes Dust Shield: No
- Includes Boot: No
- Estimated Install Time (Hours): 0.5
Installation Instructions
Warranties
Technical Bulletins
Specifications:
| PartType | Shocks / Struts |
| Body Diameter (ID) | 46mm |
| Spring Seat Included | Yes |
| Reservoir | No |
| Extended Length (IN) | 21.65 |
| Collapsed Length (MM) | 413.6 |
| Prop 65 - Short Label | WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov |
| Collapsed Length (IN) | 16.28 |
| Internal Design | Monotube |
| Upper Mount Type | Stem |
| Adjustable Damping | Non-Adjustable |
| Series | B8 5100 (Ride Height Adjustable) |
| Title | Bilstein Shock Absorbers |
| Segment | Light Truck |
| Prop 65 (Y/N) | Y |
| Boot Included | No |
| Extended Length (MM) | 550.0 |
| Lower Mount Type | Bar Pin |
| Finish | Zinc Plated |
| Body Design | Snap Ring Grooved Body (Coilover) |
| Description_FAB | Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology |
| Description_FAB | 46mm monotube design ensures consistent, fade-free performance in all conditions |
| Description_SHO | Shock |
| Description_INV | GM 1500 4WD; '19+; F; B8 5100 |
| Description_DEF | Suspension Shock Absorber |
| Description_LAB | B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber |
| Description_DES | B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber |
| Description_ASM | Chevrolet Silverado 1500 2024-2019, Silverado 1500 LTD 2022, GMC Sierra 1500 2024-2019, Sierra 1500 Limited 2022 |
| Description_EXT | 46mm Monotube Shock Absorber |
| Description_MKT | Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle. |
| Description_FAB | Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology |
